Selecting Circuit Mode
Table 3-8 describes how to set up circuit mode from the main menu.
Table 3-8: Set Up Circuit Mode
Settings
Available Options
Menu Structure
Learn More On:
Circuit Mode
Auto, Series, Parallel
Main Menu -> Test PARAM. ->
CIRC. Mode
Page 19
If auto mode is selected, series circuit mode or parallel circuit mode will be automatically identified. See Table 3-
9 for the series/parallel rules used.
Table 3-9 Auto Mode Series/Parallel Rules
Range of Component Under Test
Circuit Mode Selected in Auto Mode
C < 500 pF
Parallel Circuit Mode
C >= 500 pF
Series Circuit Mode
L
Always Series Circuit Mode
Selecting Test Frequency
Table 3-10 describes how to set up test frequency from the main menu.
Table 3-10: Set Up Test Frequency
Settings
Available Options
Menu Structure
Learn More On:
Test Frequency
Auto, 100Hz, 120Hz,
1kHz, 10kHz, 100kHz
Main Menu -> Test PARAM. ->
Test FREQU.
Page 18
NOTE
The meter is able to use auto frequency to measure capacitance approximately from 3 pF to 199 μF and
inductance approximately from 1uH to 100mH. To measure capacitance or inductance out of this range, please
select proper testing frequency manually according to Table 4-3: Measurement Ranges and Optimal Testing
Frequency.
Selecting Test Voltage
Table 3-11 describes how to set up test voltage from the main menu.
Table 3-11: Set Up Test Voltage
Settings
Available Options
Menu Structure
Learn More On:
Test voltage
0.2Vrms, 0.5Vrms,
1.0Vrms
Main Menu -> Test PARAM. ->
Test VOLT.
Page 19
NOTE
The voltage specified in the test voltage menu is root mean square (RMS) value. When converted to peak to
peak value, 0.2Vrms equals to 0.57Vp-p, 0.5Vrms equals to 1.4Vp-p and 1.0Vrms equals to 2.8Vp-p.
