LCR Pro1 User Manual

39 User Manual - LCR Pro1/Pro1 Plus - ver 1.06
Resistance Accuracy Specifications
Table 4-4 LCR Pro1/Pro1 Plus Resistance Accuracy Specification (at 1.0Vrms test voltage)
Range
Resolution
Accuracy = A
Z
+ Offset
100Hz
120Hz
1kHz
10kHz
100kHz
1000mΩ
0.01mΩ
0.5% + 20mΩ
0.5% + 20mΩ
0.5% + 20mΩ
0.5% + 20mΩ
1.0% + 20mΩ
10Ω
0.0001Ω
0.3% + 0.02Ω
0.3% + 0.02Ω
0.3% + 0.02Ω
0.3% + 0.02Ω
0.7% + 0.02Ω
100Ω
0.001Ω
0.2% + 0.03Ω
0.2% + 0.03Ω
0.2% + 0.03Ω
0.2% + 0.03Ω
0.5% + 0.03Ω
1000Ω
0.01Ω
0.2% + 0.3Ω
0.2% + 0.3Ω
0.2% + 0.3Ω
0.2% + 0.3Ω
0.3% + 0.3Ω
10kΩ
0.0001kΩ
0.2% + 0.003kΩ
0.2% + 0.003kΩ
0.1% + 0.003kΩ
0.2% + 0.003kΩ
0.5% + 0.003kΩ
100kΩ
0.001kΩ
0.1% + 0.05kΩ
0.1% + 0.05kΩ
0.1% + 0.05kΩ
0.1% + 0.05kΩ
---
1000kΩ
0.01kΩ
0.3% + 0.5kΩ
0.3% + 0.5kΩ
0.3% + 0.5kΩ
0.3% + 0.5kΩ
---
10MΩ
0.0001MΩ
2.0% + 0.008MΩ
2.0% + 0.008MΩ
2.0% + 0.008MΩ
---
---
Table 4-5 LCR Pro1/Pro1 Plus Resistance Accuracy Specification (at 0.2Vrms and 0.5Vrms test voltage)
Range
Resolution
Accuracy = A
Z
+ Offset
0.2Vrms
0.5Vrms
1000mΩ
0.01mΩ
1.0% + 20mΩ
1.0% + 20mΩ
10Ω
0.0001Ω
1.0% + 0.02Ω
1.0% + 0.02Ω
100Ω
0.001Ω
1.0% + 0.03Ω
1.0% + 0.03Ω
1000Ω
0.01Ω
1.0% + 0.3Ω
1.0% + 0.3Ω
10kΩ
0.0001kΩ
0.7% + 0.003kΩ
0.5% + 0.003kΩ
100kΩ
0.001kΩ
0.7% + 0.05kΩ
0.5% + 0.05kΩ
1000kΩ
0.01kΩ
1.0% + 0.5kΩ
1.0% + 0.5kΩ
10MΩ
0.0001MΩ
5.0% + 0.008MΩ
5.0% + 0.008MΩ
NOTE
Accuracy is specified at optimum test frequency as Table 4-3 indicates.
