ELD2-RS70** User Manual
3.2.3 Communication Port
Table 3.4 Signal Explanation of connection and debugging Port
CN7
Pin
Detail
RS232
1
5V
2
TX
3
GND
4
RX
3.2.4 Power Port
CN3
Pin
Signal
Detail
Power
terminal
1
VCC
2
GND
3
W
4
V
5
U
6
PE
3.2.5 Bus connector
Cn8
Pin
Signal
Detail
CN8
485
IN
1
RS485+
485data+
3
RS485-
485 data-
5
485GND
485 GND
other
NC
Cn9
Pin
Signal
Detail
CN8
485
IN
1
RS485+
485data+
3
RS485-
485 data-
5
485GND
485 GND
other
NC
3.2.6 Dip switch
S1
NO
485 Slave ID
NO
485 Slave ID
S1
0
Default Pr5.31=16
8
8
1
1
9
9
2
2
A
10
3
3
B
11
4
4
C
12
5
5
D
13
6
6
E
14
7
7
F
15
