4.2.7 【 Class 6 】 Special Setup
Pr5.31*
Axis address
Range
unit
default
Related
control mode
0-127
-
1
P
S
T
During communication with the host (e.g. PC) to control multiple shafts, the shaft being accessed by
the host should be identified.
Notice: when using RS232/RS485, the maximum valid value is 31.
Pr5.35*
Front panel lock setup
Range
unit
default
Related
control mode
0-1
-
0
P
S
T
Lock the operation on the front panel.
Setup value
content
0
No limit on the front panel operation
1
Lock the operation on the front panel
Pr6.03
JOG trial run command torque
Range
unit
default
Related
control mode
0 -100
%
0
T
You can set up the command speed used for JOG trial run (torque control).
Pr6.04
JOG trial run command speed
Range
unit
default
Related
control mode
0-500
r/min
300
P
S
T
You can set up the command speed used for JOG trial run (velocity control).
Pr6.07
JOG trial run command speed
Range
unit
default
Related
control mode
-100-100
%
0
P
S
T
Pr6.08
JOG trial run command speed
Range
unit
default
Related
control mode
-100-100
%
0
P
S
T
Pr6.09
JOG trial run command speed
Range
unit
default
Related
control mode
-100-100
%
0
P
S
T
This three parameters may apply feed forward torque superposition directly to torque command.
Pr6.20
Trial run distance
Range
unit
default
Related
control mode
0-200
0.1rev
10
P
The distance of running each time in JOG run(position control)
Pr6.21
Trial run waiting time
Range
unit
default
Related
control mode
0-30000
Ms
1000
P
The waiting time after running each time in JOG run(position control)
