ELD2-RS70** User Manual
Electronic gear ratio error
I/F input interface allocation error
●
●
I/F input interface function set error
●
●
I/F output interface function set error
●
●
CRC verification error when EEPROM
parameter saved
Positive/negative over-range input valid
●
●
●
Analog value 1 input error limit
Compulsory alarm input valid
●
●
Motor code error
Save: save this error history record
Emergency: error, driver will stop immediately
May remove: may through SI input/panel/software ACH Series remove alarm
5.2 Alarm Processing Method
When appear error, please clear error reason, renew power on
Error
code
Main
Extra
Display: “ ”--“ ”
~
Content: FPGA communication error
Cause
Confirmation
Solution
Vdc/GND under-voltage
Check the voltage of
Vdc/GND terminal
Make sure voltage of Vdc/GND in proper range
Driver internal fault
/
replace the driver with a new one
Error
code
Main
Extra
Display:’ ”--“ ”
~
Content: current detection circuit error
Cause
Confirmation
Solution
Wiring error of motor output
U,V,W terminal
Check wiring of motor output
U,V,W terminal
Make sure motor U,V,W terminal wiring
correctly
Vdc/GND under-voltage
Check the voltage of
Vdc/GND terminal
Make sure voltage of Vdc/GND in
proper range
Driver inner fault
/
replace the driver with a new one
Error
code
Main
Extra
Display: “ ”--“ ”
~
Content: analog input circuit error
Cause
Confirmation
Solution
Analog input Wiring error
Check wiring of analog input
Make sure analog input wiring correctly
Driver inner fault
/
replace the driver with a new one
