Extended Setup
2nd numerator of electronic gear
3rd numerator of electronic gear
4th numerator of electronic gear
Denominator of pulse output division
According to the command pulse input , set the 2nd to 4th numerator of electronic gear
numerator of electronic gear
denominator of electronic gear
For details, refer to Pr0.11 .
Specify the status during deceleration and after stop, after servo-off.
LV trip selection at main power OFF
You can select whether or not to activate Err0d.0 (main power under-voltage protection)function
while the main shutoff continues for the setup of Pr5.09(The main power-OFF detection time).
Action of main power low voltage protection
When the main power is shut off during Servo-On,Err0d.0 will not be triggered and
the driver turns to Servo-OFF. The driver returns to Servo-On again after the main
power resumption.
When the main power is shut off during Servo-On, the driver will trip due to
Err0d.0
Caution: Err0d.0(main power under-voltage protection) is trigged when setup of Pr5.09 is long and
P-N voltage of the main converter falls below the specified value before detecting the main power
shutoff , regardless of the Pr5.08 setup.
The main power-OFF detection time
You can set up the time to detect the shutoff while the main power is kept shut off continuously. The
main power off detection is invalid when you set up this to 2000.
