0x6230~0x6237
Pr9.48~Pr9.55
PR6 parameters
The same with Pr9.00~Pr9.07
0x6238~0x623f
Pr9.56~Pr9.63
PR7 parameters
The same with Pr9.00~Pr9.07
0x6240~0x6247
Pr9.64~Pr9.71
PR8 parameters
The same with Pr9.00~Pr9.07
0x6248~0x624f
Pr9.72~Pr9.79
PR9 parameters
The same with Pr9.00~Pr9.07
0x6250~0x6257
Pr9.80~Pr9.87
PR10 parameters
The same with Pr9.00~Pr9.07
0x6258~0x625f
Pr9.88~Pr9.95
PR11 parameters
The same with Pr9.00~Pr9.07
0x6260~0x6267
Pr9.96~Pr9.103
PR12 parameters
The same with Pr9.00~Pr9.07
0x6268~0x626f
P9.104~Pr9.11
1
PR13 parameters
The same with Pr9.00~Pr9.07
0x6270~0x6277
Pr9.112-Pr119
PR14 parameters
The same with Pr9.00~Pr9.07
0x6278~0x627f
Pr9.120-Pr127
PR15 parameters
The same with Pr9.00~Pr9.07
7.4.2 485 communication Installation wiring
Bus connector
Cn8
Pin
Signal
Detail
CN8
485
IN
1
RS485+
485data+
3
RS485-
485 data-
5
485GND
485 GND
other
NC
Cn9
Pin
Signal
Detail
CN9
485
OUT
1
RS485+
485data+
3
RS485-
485 data-
5
485GND
485 GND
other
NC
Do not use RS232 communication port，that is for parameters setting only
