ELD2-RS70** User Manual
4.2.8 【 Class 7 】 Factory setting
Pr6.22
Trial run cycle times
Range
unit
default
Related
control mode
0-32767
-
10
P
The cycling times of JOG run(position control)
Pr7.15
Motor model input
Range
unit
default
Related
control mode
0-8FFF
-
P
S
T
Pr7.16
Encoder selection
Range
unit
default
Related
control mode
P
S
T
Motor Model
Pr7.15
Pr7.16
ACM602V36-1000
0x8001
0x201
ACM602V36-2500
0x8001
0x204
57BL180D-1000
0x8003
0x201
ACM604V60-1000
0x8002
0x201
ACM604V60-2500
0x8002
0x204
ELDM6020V36H-A5
0x8004
0x201
ELDM602V36-T-2500
0x8006
0x204
ELDM602V24-T-2500
0x8007
0x204
ELDM4005V24HL-B5
0x8008
0x204
ELDM4010V24HL-B5
0x8009
0x204
ELDM6020V48HL-A5
0x800B
0x201
ELDM6040V48HL-A5
0x800C
0x201
ELDM6040V60HL-A5
0x800D
0x201
ELDM6060V48HL-A5
0x800E
0x201
ELDM8075V48HM-A4
0x8010
0x201
Pr7.32
Threshold value setting of
regenerative resistor
Range
unit
default
Related
control mode
20-90
V
80
P
S
T
When the bus voltage is greater than the set value of Pr7.32, switch on the regenerative resistor and
absorb regenerative energy to protect the drive.
