19
ELD2-RS70** User Manual
t
qh
＞4μs
＞5μs
t
ql
＞4μs
＞5μs
t
qrh
＜0.2μs
＜0.3μs
t
qrl
＜0.2μs
＜0.3μs
t
qs
＞1μs
＞2.5μs
Figure 3.8 pulse + direction input interface timing (the maximum of pulse frequency : 500KHZ)
