64
UserManualforELD2Servo
7.2.2 9th sort parameters specification
No.
Name
Data
type
Range
Default
value
Definition
P9.0
PR1 Mode
hex
0
PR
p
ath mode, determine the action according to
type property
Bit0-3:TYPE , 0 No Action /1 location
positioning /2 speed running /3 homing,
use P/V/H to express
Bit4:INS,0 do no interrupt / 1 interrupt, Use !
to express interrupt , _ express interrupt (
Currently, they are all interrupt) Bit5:OVLP
,0 do not overlap /1 overlap, Use SJ to
express no, overlap jump, use CJ to
express overlap jump, (right now no)
Bit6-7:0 absolute/1 relative instruction/2 relative
to the motor/3 opposite reference value,
ABS/INC/REL/CAP( right now only ABS、
INC、REL)
Bit8-13:0-15 Jump to the corresponding path,
Use SJ0x or CJ0x to express.
bit14:JUMP,0 No jump,1 jump , No jump
use END to express, jump use SJ or CJ。
(SJ: stop and jump, CJ: continue and jump)
