Leadshine ELD2 Series - Analog Value Input Interface; Servo Motor Encoder Input Interface

18
UserManualforELD2Servo
t
q
h ＞ 4
μ
s ＞ 5
μ
s
t
q
l ＞ 4
μ
s ＞ 5
μ
s
t
q
rh
＜ 0.2
μ
s ＜ 0.3
μ
s
t
q
rl
＜ 0.2
μ
s ＜ 0.3
μ
s
t
q
s
＞ 1μs ＞ 2.5μs
Figure3.8pulse+directioninputinterfacetiming(themaximumofpulsefrequency:500KHZ)
3.3.4 Analog Value Input Interface

Figure3‐9AnalogInputInterface
3.3.5 Servo Motor Encoder Input Interface

Figure3‐11ServoMotoroptical‐electricalEncoderInputInterface








