Valve Bank Assembly (400T Only) Parts List
Item
No.
Part Number Qty. Description Remarks
Ref 1000487 1 Valve, 3-Section, Vo40
1 670230 1 Mounting Kit, Valve Lever
2 670230 1 Clevis, Valve Spool End
3 670220 2 Bracket, Valve Lever Pivot
4 510180 1 Valve, Relief, V-12
5 510190 1 End Cover, Rh
6 510200 1 Pintle Eye, 2 1/2”
7 510210 1 Stud Kit
8 510220 1 Spring Return Kit
9 510230 1 Cover, Valve Spool
10 510240 1 O-Ring Kit, V-12 Valve Section
11 510250 1 Load Check Kit
12 510260 1 Valve Section, Spring Return
13 984849 1 Valve Assembly, 3-Section
Note: The 400 Model Does Not Have A Valve
Bank Assembly.
7
Illustrated Parts List
LeeBoy Model 400 & 400T Rollers 7-45
