LeeBoy 400T - Lubrication Points

LUBRICATION POINTS
Proper lubrication is necessary to maintain the machine
at top efciency. Lubrication points are shown in the
following gure. Lubricate these ttings every 40 hours
for optimum performance.
NOTE: Grease with Shell Avania EP Grease or
equivalent.
1
7
2
3
4
5
6
8
9
10
Figure 5-1. Lubrication Points
Maintenance
LeeBoy Model 400 & 400T Rollers5-4
