LeeBoy 400T - Hydraulic Levers (400 T Only)

HYDRAULIC LEVERS (400T ONLY)
1
3
2
Figure 3-3. Hydraulic Levers
ITEM NO. CONTROL NAME FUNCTION
1 Tongue Lever Raises and lowers tongue.
2 Left Wheel Lever Raises and lowers left wheel.
3 Right Wheel Lever Raises and lowers right wheel.
Component Location
LeeBoy Model 400 & 400T Rollers3-6
