Table 3-1. Location of Operation Panels and Controls
ITEM
NO.
CONTROL NAME FUNCTION
1
Engine and Battery
Access Compartment
Used to access engine and battery. Located on right side of the roller.
2
Hydraulic Oil Reservoir
Tank Access
Used to access hydraulic oil reservoir. Located on the right side of the roller
below the air cleaner.
3 Step (Left and Right Side) Used to enter and exit the operator station.
4 Fuel Tank Compartment Location for lling diesel fuel.
5 Work Light (OPTION) Used to illuminate in front of the machine during operation.
6
Forward/Neutral/Reverse
(FNR) Lever
Controls forward and reverse operation and variable speed of the traction
pump.
7 Steering Wheel Steers machine.
8 Operator’s Control Panel
Group includes the Ignition Switch, THe Digital Usage Display, the Warning
Light, the Water Sprayer Switch, as well as the Wait to Start Switch.
9 Tow Bar (400T Only) Towing bar (Optional) available only on the Model 400T.
10 Hydraulic CYLINDER Used to lift/lower the tow wheels for towing purposes.
11 Operator’s Seat Operator’s seat for controlling machine operation.
12
ROPS (Roll Over
Protection System) Bar
Safety bar.
13 Operator Manual Location for this manual.
14 Tow Leg (400T Only)
Used to tow the roller.
15
Hydraulic Oil Level/
Temperature Gauge
Gauge that shows ll level and temperature of hydraulic oil.
16
Hydraulic Supply Line
Gate Valves Access
Used to turn on and off hydraulic supply lines.
17 Water Reservoir/Fill Cap
Cools the drum to prevent asphalt from sticking to the drum surface during
operation.
18
Retractable Wheels
(400T Only)
Used for towing the machine.
19 Canopy (Optional) Protects operator from sunlight, falling debris and light rain.
20 Front Roller Used for asphalt compaction and steering.
21 Rear Roller Used for asphalt compaction.
22 Water Line/Spray Sprays machine with water when engaged.
23 Tail Lights (400T Only) Tail light illuminates for towing.
24 Beacon Light Safety ashing light.
* Throttle (Not Shown)
Used to increase/decrease the throttle on the engine. Located on the left-side
of the steering column.
3
Component Location
LeeBoy Model 400 & 400T Rollers 3-5
