LeeBoy 400T - Page 91

400 Main Frame Assembly, 2 of 2, Parts List
Item
No.
Part Number Qty. Description Remarks
1 987151 1 Weldment, Frame 400
2 989117 2 W/M, Hinge Assembly, Water Tank Plate
3 400762 1 Shaft, Control
4 857137 1 Key Stock
Ref 490092 1 Handle, 400 Lh Drive Assembly
5 490071 1 Spacer
6 490080 1 Washer, Belleville 5/8”
7 400781 1 Threaded Rod & Tube
8 300213 1 Support, Plate Floorboard welded to 300212
9 1009905 1 Lever, Forward/Reverse-Rh welded to 857135
10 100-8-13-32-5 4 Cshh, 1/2-13 X 2, Gr5
11 100-6-16-24-5 1 Cshh, 3/8-16 X 1.5, Gr5
12 102-607-1A 1 Cshh, .625-11 X 1.500, Gr5
13 118-5 4 Washer, Lock, .500
14 300-6 6 Washer, Flat, Sae, 3/8
15 200-8-13-5 4 Nut, Hex, 1/2-13, Gr5
16 116-3 3 Nut, Hex, .375-16
17 858526 1 Rnd, .688 X 8.75, Crs
18 400761 1 Bushing, Drive Handle, Lh, 400 welded to 400764
19 300-6 2 Washer, Flat, Sae, 3/8
20 100-6-16-36-5 1 Cshh, 3/8-16 X 2.25, Gr5
21 1009904 1 Handle, 400 Lh Drive
7
Illustrated Parts List
LeeBoy Model 400 & 400T Rollers 7-7
