Rear Drum Assembly Parts List
Item
No.
Part Number Qty. Description Remarks
1 400887-04 1 Rear Drum, I.d. Machined
2 520280 1 Flange W/Hub,Inner Bearing Support-400
3 520060 1 Bearing, Insert,1.50
4 858248 1 Vibrator Hub/400
5 400595 1 Hub, Counterweight
6 400596 1 Counter Weight, Vibe
7 988504 1 Motor, Hydraulic, Gear, .67Cir
8 300-6 2 Washer, Flat, Sae, 3/8
9 300-8 2 Washer, Flat, Sae, 1/2
10 118-3 2 Washer, Lock, .375
11 118-6 12 Washer, Lock, .562
12 118-5 42 Washer, Lock, .500
13 102-6-16-20-F 2 Cssh, 3/8-16 X 1.25, Ft
14 858312 1 Vibrator Hub To Frame Mount
15 100-10-11-24-8F 12 Cshh, 5/8-11 X 1.5, Gr8, Ft
16 100-8-13-24-5 24 Cshh,1/2-13 X 1.5, Gr5
17 100-8-13-16-5F 16 Cshh, 1/2-13 X 1, Gr5, Ft
18 100-8-13-20-8F 2 Cshh, 1/2-13 X 1.25, Gr8, Ft
19 858309 2 Mount, Motor To Frame (400 W/Poclain)
20 520020A 6 Shear Mount, Frame To Drum
21 200-8-13-5 24 Nut, Hex, 1/2-13, Gr5
22 116-7 9 Nut, Hex, .625-11
23 986811 9 Washer, Lock, .670, Nord Wedge
24 811361 1 Motor, Hyd, Drive, 7000
7
Illustrated Parts List
LeeBoy Model 400 & 400T Rollers 7-15
