5.4008.8573.0 B
Operating Instructions 5-23
3. Switch the battery on with the On/Off button (1).
The LED on the battery will not go on.
Figure 25. On/Off buttons
KEY: 1. Battery on/off button - 2. VIOB on/off button
• Make sure the button on the battery is pushed in (push it a few times and feel when the button
stays in or out).
• If the battery went off automatically because it was emptied to less than 30% you must push the
battery button out and in again.
4. Close the cover and with 2 persons slowly push the machine under the charger with a maximum speed
similar to the driving speed of the machine.
Do not push the machine too fast because otherwise the electronics will be damaged.
The maximum allowed speed is 0.2 m/s (0.7 ft/s), which is similar to the normal driving
speed.
