Parameter setting with the XT EMZ9371BC keypad
Menu structure
9
Parameter setting
9.4
9.4.8
L
9.4-16
EDS82EV903-1.0-11/2002
Main menu DescriptionSubmenus
No.
Description
DisplayNo.Display
13 FIF fieldbus Configuration operation with fieldbus function modules
and display of the p rocess data word contents
Only active with fieldbus function module
13.1 Identify Software state display and type fieldbus function module
13.2 FIF managem FIF communication parameters
13.3 POW setup Process data from master to fieldbus function module
13.4 PIW setup Process data from fieldbus function module to master
13.5 Com.err setup Communication monitoring
Change to the code level to display the contents of the data words. The contents of the data
words a re displayed as decimal value.
13.6 Monit PIW Process data display from fieldbus function module to master
13.7 Monit POW Process data display from master to fieldbus function module
13.8 Monit FIF-IN Process data display from fieldbus function module to
controller
13.9 Monit FIF-OUT Process data display from controller to fieldbus function
module
14 Motor/Feedb. Input of motor data, configuration of speed feedback
14.1 Motor data Motor data
14.2 F eedback DFIN F requency input DFIN, encoder
15 Identify I dentification
15.1 Drive Software version controller
15.2 Keypad Software version keypad
15.3 FIF module Software version and function module type
