Lenze E82EV751K4C User Manual

Free connection of digital signals
Free configuration of digital outputs
10
Function library
10.13
10.13.2
L
10.13-8
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0415
Possible d igital sign als for C0415
^
v
(cont.)
20 Apparent motor current < current threshold
(DCTRL1-IMOT<ILIM)
Belt monitoring
Apparent motor current = C0054
10.13-6
(
)
21 Apparent motor current < current threshold and
output frequenc y > frequency threshold Q
min
(DCTRL1-(IMOT<ILIM)-QMIN)
p
p
Current t hreshold = C0156
Frequency threshold Q
min
= C0017
22 Apparent motor current < current threshold and
RFG 1: Input = output
(DCTRL1-(IMOT<ILIM)-RFG-I= 0)
23 Motor phase fa ilure warning (DCTRL1-LP1-WARN) Set C0597 = 2
24 Minimum output frequency reached (f ≤ C0010)
(PCTRL1-NMIN)
LOW active
25 TRIP fault message (DCTRL1-TRIP)
26 Motor is running (DCTRL1-RUN)
27 Motor is running/CW rotation (DCTRL1-RUN-CW)
28 Motor is running/CCW rotation
(DCTRL1-RUN-CCW)
29 Process controller input = process controller
output (PCTRL1-SET=ACT)
30 Reserved
31 Apparent motor current> current threshold and
ramp function generator 1: Input = output
(DCTRL1-(IMOT>ILIM)-RFG-I= 0)
Overload monitoring
Apparent motor current = C0054
Current t hreshold = C0156
32 Digital input X3/E1
Digital inputs
33 Digital input X3/E2
g
p
34 Digital input X3/E3
35 Digital input X3/E4
36 (A ) Digital input X3/E5
37 (A ) Digital input X3/E6
38 PTC input X2.2/T1, X2.2/T2 T1/T2 can only be connected to
potential-free switches!
T1/T2 is active (”HIGH”) when the swit ch is
closed
