4 Technical data
4.1 General data and operating conditions
Range Values
Order designation E84AYCER
Communication profile PROFINET
Communication medium S/FTP (Screened Foiled Twisted Pair, ISO/IEC 11801 or EN 50173), CAT 5e
Interface for communication RJ45: Standard Ethernet (in accordance with IEEE 802.3), 100Base-TX (Fast
Ethernet)
Network topology Tree, star, and line
Type of node I/O device with real time (RT) communication properties
Number of device nodes Max. 255 in the subnetwork
Max. cable length 100 m
PNO identification number 0x0106
Device identification (Device ID) 0x8400
TCP port 8410
Baud rate 100 Mbps
Switching method "Store and forward"
Switch latency Approx. 125 μs at max. frame length
Voltage supply External supply via separate power supply unit
• "+": U = 24 V DC (20.4 V - 0 % ... 28.8 V + 0 %), I = 140 mA
• "-": Reference potential for external voltage supply
Conformities, approvals CE 2004/108/EC, EMC Directive
2006/95/EC, Low-Voltage Directive
EAC Eurasian conformity
TR CU: Technical Regulations of Customs Union
TP TC 004/2011 (TR CU 004/2011)
About the safety of low voltage equipment
TP TC 020/2011 (TR CU 020/2011)
Electromagnetic compatibility of technical means
UL UL 508C / C22.2 No. 14,
Power Conversion Equipment (File-No. E132659)
Hardware manual "Inverter Drives 8400"
Here you can find the ambient conditions and data on the electromagnetic compatibility
(EMC), which also apply to the communication module.
