Technical data
Protocol data
19
Lenze · E84AYCER communication module (PROFINET) · EDS84AYCER EN 3.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.3 Protocol data
4.4 Communication time
The communication time is the time between the start of a request and the arrival of the correspon-
ding response.
The communication times in the PROFINET network depend on the ...
• processing time in the inverter;
• frame runtime (baud rate / frame length);
• nesting depth of the network.
Processing time inside the inverter
There are no interdependencies between parameter data and process data.
Range Values
Process data words (PCD) Max. 16 process data words (max. 32 bytes)
Acyclic parameter data channel Limited by the PROFINET frame size
Data Processing time
Process data Approx. 2 ms
+ 0 ... 1 ms
+ 1 ... x ms
Update cycle
Processing time in the module
Runtime of the application task of the technology applicati-
on used (tolerance)
Parameter data Approx. 30 ms + a tolerance of 20 ms (typically)
• For some codes, the processing time may be longer (see software manu-
al/»Engineer« online help for the Inverter Drive 8400).
