Lenze · E84AYCER communication module (PROFINET) · EDS84AYCER EN 3.0 - 02/2019 35
Commissioning
Configuring the PROFINET IO controller
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.2 Configuring the PROFINET IO controller
To enable communication with the inverter, you have to configure the IO controller first.
Configuration for device control
For the configuration of PROFINET, the current PROFINET device description file (XML) of the
E84AYCER communication module (PROFINET) has to be imported in the IO controller.
You can find the GSDML-Vx.z-Lenze-8400PNabb-yyyymmdd.xml device description file in the
Download area at:
www.Lenze.com
Defining the user data length
The user data length is defined during the initialisation phase of the I/O controller.
The Inverter Drives 8400 support the configuration of max. 16 process data words (max. 32 bytes).
Description of the device data base file
Example of selecting the device data base file
• "PCD (8W) AR cons." = 8 process data words (only in slot 1 of the PROFINET telegram)
Tip!
A detailed description of consistency is given in the chapter "Consistent parameter data
"
( 70).
Wildcards in the "GSDML-Vx.z-Lenze-8400PN100-yyyymmdd.xml" file name
x Main version of the GSDML scheme used
z Subversion of the GSDML scheme used
a Major version of the software version
bb Minor version of the software version
yyyy Year
mm Month
dd Day
Selection text Parameter data
(with consistency)
Process data
(with consistency)
Assigned
I/O memory
PCD (nW) AR cons. - n words n words
n = 1 ... 16 process data words
