Lenze · E84AYCER communication module (PROFINET) · EDS84AYCER EN 3.0 - 02/2019 86
Parameter reference
Parameters of the communication module
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13001
C13002
C13003
Parameter | Name:
C13001 | Subnetwork mask
Data type: UNSIGNED_32
Index: 11574
d
= 2D36
h
Setting of the subnet mask
Setting the IP configuration
( 38)
Setting range (min. value | unit | max. value) Lenze setting
0 4294967295 0
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13002 | Gateway address
Data type: UNSIGNED_32
Index: 11573
d
= 2D35
h
Setting of the gateway address
Setting the IP configuration
( 38)
Setting range (min. value | unit | max. value) Lenze setting
0 4294967295 0
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13003 | Physical address
Data type: OCTET_STRING
Index: 11572
d
= 2D34
h
Display of the MAC-ID
Subcodes Info
C13003/1 MAC ID: Station
C13003/2 MAC ID: Port1
C13003/3 MAC ID: Port2
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
