Firmware 03.00 - DMS EN 5.0 - 07/2009 L 139
8400 BaseLine D | Software Manual
Drive Application
Overview of the software structure of the drive application function | Functions of the drive application
Selection of the control type
The selection of the control type determines how the drive application of the BaseLine is to be controlled. The following types are
available:
1. Terminal control (Lenze setting)
2. Control via internal keypad / PC
The device inputs and outputs called system blocks at Lenze are the interfaces between the (internal) drive application and the
peripheral inputs and outputs of the controller. The terminals, for instance, are important inputs and outputs for the user. The
frequency inverter has one analog input and several digital inputs and outputs.
The interconnections between system blocks and the drive application are assigned with code C007
. An overview of the signals
affecting the inputs and outputs of the drive application is provided by the table in chapter Pre-assignment of the drive application
( 140). Die Tabelle gibt die Verknüpfungen in der Lenze-Einstellung wieder..
