Firmware 03.00 - DMS EN 5.0 - 07/2009 L 175
8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00003
C00003
C00002/17 0: Off / ready Activate quick stop
"1" ≡ Activate quick stop
"0" ≡ Deactivate quick stop
C00002/18 0: Off / ready Reserved
C00002/19 0: Off / ready Reset error
• After the reset of the current error, other errors may
be pending which must be reset as well.
• Details on the currently pending error are displayed in
C00166
.
C00002/20 0: Off / ready Reserved
C00002/21 0: Off / ready Delete logbook
• All entries in the logbook of the controller will be de-
leted.
• Information about the error history is saved in the
logbook.
C00002/22 0: Off / ready Reserved
C00002/23 0: Off / ready Identify motor parameters
• This device command serves to carry out an automat-
ic identification of the motor parameters.
• The device command is only carried out if the control-
ler is in the Switched On status
• In order to identify the motor parameters, the con-
troller must be enabled after this device command.
C00002/24 0: Off / ready Reserved
C00002/25 0: Off / ready Reserved
C00002/26 0: Off / ready Reserved
C00002/27 0: Off / ready Reserved
C00002/28 0: Off / ready Reserved
C00002/29 0: Off / ready Reserved
C00002/30 0: Off / ready Reserved
C00002/31 0: Off / ready Reserved
C00002/32 0: Off / ready Reserved
; Read access ; Write access CINH PLC STOP ; No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00002 | Controller commands
Data type: UNSIGNED_8
Index: 24573
d
= 5FFD
h
Parameter | Name:
C00003 | Status of last device command
Data type: UNSIGNED_8
Index: 24572
d
= 5FFC
h
Status of the device command executed last (C00002).
Note:
Before switching off the supply voltage after executing a device command, check the successful execution of the
device command by means of this status display!
Drive control (DCTRL)
: Device commands
Selection list (read only) Info
0 Successful Device command has been executed successfully.
1 Command unknown Device command is implausible or not known in the sys-
tem.
2 No access Access for required device command is not approved.
3 Time-out Processing of the device command could not be executed
within the defined time (time-out).
; Read access Write access CINH PLC STOP ; No transfer COM MOT Scaling factor: 1
