Lenze L-force 8400 BaseLine D - Page 211

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 211
8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00700
C00700
C00621/15 0: Not connected Reserved
C00621/16 0: Not connected Ls_DisFree_b: bDis1
C00621/17 0: Not connected Ls_DisFree_b: bDis2
C00621/18 0: Not connected Ls_DisFree_b: bDis3
C00621/19 0: Not connected Ls_DisFree_b: bDis4
C00621/20 0: Not connected Ls_DisFree_b: bDis5
C00621/21 0: Not connected Ls_DisFree_b: bDis6
C00621/22 0: Not connected Ls_DisFree_b: bDis7
C00621/23 0: Not connected Ls_DisFree_b: bDis8
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00621 | Bool system connection
Data type: UNSIGNED_16
Index: 23954
d
= 5D92
h
Parameter | Name:
C00700 | LA_NCtrl: analog connection list
Data type: UNSIGNED_16
Index: 23875
d
= 5D43
h
Connection parameters for "Actuating drive - speed" application: 16-bit inputs
• Selection of the 16-bit output signals for connection with the 16-bit input signals
• The selection list contains all 16-bit output signals which can be assigned to the 16-bit inputs mapped by the
subcodes.
Selection list Info
0Not connected
1 C_nPos100_a(100.0%)
2 C_nNeg100_a(-100.0%)
3 C_nPos199_9_a(199.9%)
4 C_nNeg199_9_a(-199.9%)
5 C_w65535
6C_wDriveCtrl
10 AIn1_Out
20 nPar1_a
21 nPar2_a
22 nPar3_a
23 nPar4_a
24 LS_Keypad_nTorqueMotLim_a
25 LS_Keypad_nTorqueGenLim_a
26 LS_Keypad_nMainSetValue_a
50 LA_NCTRL_nMotorFreqAct_a
51 LA_NCTRL_nOutputSpeedCtrl_a
52 LA_NCtrl_nMotorSpeedAct_a
53 LA_NCtrl_nMotor Voltage_a
54 LA_NCtrl_nDCVoltage_a
55 LA_NCtrl_nMotorCurrent_a
56 LA_NCtrl_nMotorTorqueAct_a
57 LA_NCTRL_nHeatsinkTemperature_
a
70 LA_NCTRL_wDeviceStateWord
71 LA_NCTRL_wDeviceAuxStateWord
72 LA_NCTRL_wDetermFailNoLow
