Lenze L-force 8400 BaseLine D - Page 210

8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00621
210 L Firmware 03.00 - DMS EN 5.0 - 07/2009
29 bPar10
30 bPar11
31 bPar12
32 bPar13
33 bPar14
34 bPar15
35 bPar16
36 LS_Keypad_bSetQuickstop
37 LS_Keypad_bSetDCBrake
38 LS_Keypad_bSetSpeedCcw
39 LS_Keypad_bJogSpeed1
40 LS_Keypad_bJogSpeed2
50 LA_nCtrl_bDriveFail
51 LA_nCtrl_bDriveReady
52 LA_nCtrl_bCInhActive
53 LA_nCtrl_bQSPIsActive
54 LA_NCtrl_bSafeTorqueOff
55 LA_NCtrl_bSafetyIsActive
60 LA_nCtrl_bSpeedCcw
61 LA_nCtrl_bActSpeedEqZero
62 LA_nCtrl_bSpeedSetReached
63 LA_nCtrl_bSpeedActEqSet
64 LA_nCtrl_bNActCompare
65 LA_nCtrl_bImaxActive
66 LA_nCtrl_bHeatSinkWarning
67 LA_nCtrl_bOVDetected
68 LA_nCtrl_bDCBrakeOn
69 LA_NCtrl_bFlyingSyncActive
70 Ain_bCurrentErrorIn1
Subcodes Lenze setting Info
C00621/1 50: LA_nCtrl_bDriveFail LS_DigitalOutput: bRelay
C00621/2 51: LA_nCtrl_bDriveReady LS_DigitalOutput: bOut1
C00621/3 0: Not connected Reserved
C00621/4 0: Not connected Reserved
C00621/5 0: Not connected Reserved
C00621/6 64: LA_nCtrl_bNActCompare USER LED
C00621/7 0: Not connected LA_NCtrl: bStatusBit0
C00621/8 65: LA_nCtrl_bImaxActive LA_NCtrl: bStatusBit2
C00621/9 62: LA_nCtrl_bSpeedSetReached LA_NCtrl: bStatusBit3
C00621/10 63: LA_nCtrl_bSpeedActEqSet LA_NCtrl: bStatusBit4
C00621/11 64: LA_nCtrl_bNActCompare LA_NCtrl: bStatusBit5
C00621/12 60: LA_nCtrl_bSpeedCcw LA_NCtrl: bStatusBit14
C00621/13 51: LA_nCtrl_bDriveReady LA_NCtrl: bStatusBit15
C00621/14 0: Not connected Reserved
Parameter | Name:
C00621 | Bool system connection
Data type: UNSIGNED_16
Index: 23954
d
= 5D92
h
