Firmware 03.00 - DMS EN 5.0 - 07/2009 L 213
8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00701
38 LS_Keypad_bSetSpeedCcw
39 LS_Keypad_bJogSpeed1
40 LS_Keypad_bJogSpeed2
50 LA_nCtrl_bDriveFail
51 LA_nCtrl_bDriveReady
52 LA_nCtrl_bCInhActive
53 LA_nCtrl_bQSPIsActive
54 LA_NCtrl_bSafeTorqueOff
55 LA_NCtrl_bSafetyIsActive
60 LA_nCtrl_bSpeedCcw
61 LA_nCtrl_bActSpeedEqZero
62 LA_nCtrl_bSpeedSetReached
63 LA_nCtrl_bSpeedActEqSet
64 LA_nCtrl_bNActCompare
65 LA_nCtrl_bImaxActive
66 LA_nCtrl_bHeatSinkWarning
67 LA_nCtrl_bOVDetected
68 LA_nCtrl_bDCBrakeOn
69 LA_NCtrl_bFlyingSyncActive
70 Ain_bCurrentErrorIn1
Subcodes Lenze setting Info
C00701/1 0: Not connected LA_NCtrl: bCInh
C00701/2 15: DigIn_CInh LA_NCtrl: bFailReset
C00701/3 0: Not connected LA_NCtrl: bSetQuickstop
C00701/4 13: DigIn_bIn3 LA_NCtrl: bSetDCBrake
C00701/5 14: DigIn_bIn4 LA_NCtrl: bSetSpeedCcw
C00701/6 11: DigIn_bIn1 LA_NCtrl: bJogSpeed1
C00701/7 12: DigIn_bIn2 LA_NCtrl: bJogSpeed2
C00701/8 0: Not connected LA_NCtrl: bMPotUp
C00701/9 0: Not connected LA_NCtrl: bMPotDown
C00701/10 0: Not connected LA_NCtrl: bMPotInAct
C00701/11 0: Not connected LA_NCtrl: bMPotEnable
C00701/12 0: Not connected LA_NCtrl: bRFG_0
C00701/13 0: Not connected LA_NCtrl: bSetError1
C00701/14 0: Not connected LA_NCtrl: bSetError2
C00701/15 1: C_bTrue LA_NCtrl: bPIDInfluenceRamp
C00701/16 0: Not connected LA_NCtrl: bPIDIOff
C00701/17 1: C_bTrue LA_NCtrl: bRLQCw
C00701/18 0: Not connected LA_NCtrl: bRLQCcw
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00701 | LA_NCtrl: digital connection list
Data type: UNSIGNED_16
Index: 23874
d
= 5D42
h
