Lenze L-force 8400 BaseLine D - Page 214

8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00725
214 L Firmware 03.00 - DMS EN 5.0 - 07/2009
C00725
C00727
C00728
C00800
Parameter | Name:
C00725 | Current switching frequency
Data type: UNSIGNED_8
Index: 23850
d
= 5D2A
h
From version 03.00.00
Display of the current switching frequency
• When a variable switching frequency is selected in C00018
, the switching frequency may change as a function
of the load and rotational frequency.
Selection list (read only)
1 4 kHz var./drive-optimised
2 8 kHz var./drive-optimised
3 16 kHz var./drive-optimised
5 2 kHz constant/drive-optimised
6 4 kHz constant/drive-optimised
7 8 kHz constant/drive-optimised
8 16 kHz constant/drive-optimised
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00727 | LS_Keypad: Digital values
Data type: UNSIGNED_8
Index: 23848
d
= 5D28
h
Executing control commands when operating via keypad
Setting range (min. value | unit | max. value)
01
Subcodes Lenze setting Info
C00727/1 0 "1" ≡ request quick stop
C00727/2 0 "1" ≡ request DC-injection braking
C00727/3 0 "1" ≡ request reversal
C00727/4 0 "1" ≡ request fixed speed setpoint 1
C00727/5 0 "1" ≡ request fixed speed setpoint 2
; Read access ; Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00728 | LS_Keypad: Keypad analog values
Data type: INTEGER_16
Index: 23847
d
= 5D27
h
Selection of different setpoints when operating via keypad
Setting range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Lenze setting Info
C00728/1 100.0 % Torque limit in motor mode
C00728/2 100.0 % Torque limit in generator mode
C00728/3 0.0 % Setpoint speed
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00800 | L_MPot_1: Upper limit
Data type: INTEGER_16
Index: 23775
d
= 5CDF
h
FB L_MPot_1: Upper limit of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 100.0 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
