Lenze L-force 8400 BaseLine D - Page 215

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 215
8400 BaseLine D | Software Manual
Parameter reference
Parameter list | C00801
C00801
C00802
C00803
C00804
C00805
Parameter | Name:
C00801 | L_MPot_1: Lower limit
Data type: INTEGER_16
Index: 23774
d
= 5CDE
h
FB L_MPot_1: Lower limit of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 -100.0 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00802 | L_MPot_1: Acceleration time
Data type: UNSIGNED_16
Index: 23773
d
= 5CDD
h
FB L_MPot_1: Acceleration time of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
0.1 s 999.9 10.0 s
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00803 | L_MPot_1: Deceleration time
Data type: UNSIGNED_16
Index: 23772
d
= 5CDC
h
FB L_MPot_1: Deceleration time of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
0.1 s 999.9 10.0 s
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00804 | L_MPot_1: Inactive function
Data type: UNSIGNED_8
Index: 23771
d
= 5CDB
h
FB L_MPot_1: Selection of the response when deactivating the motor potentiometer via the bInAct input
Selection list (Lenze setting printed in bold) Info
0 Keep value Keep output value
1 Deceleration to 0 Deceleration via ramp to 0
2 Deceleration to lower limit Deceleration via ramp via the lower limit (C00801
)
3 Without ramp to 0 Jump to 0
4 Without ramp to lower limit Jump to lower limit (C00800
)
5 Acceleration to upper limit Acceleration via ramp to upper limit (C00800)
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00805 | L_MPot_1: Init fct.
Data type: UNSIGNED_8
Index: 23770
d
= 5CDA
h
FB L_MPot_1: Selection of the response when switching on the device
Selection list (Lenze setting printed in bold)
0 Load last value
1 U. Load limit
2Load 0
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
