LevelOne GES-2450 - 802.1 X; 802.1 X Setting

Web Smart Switch
58
Name
Type a descriptive name (up to 32 printable ASCII characters) for this
filtering rule. This is for identification only.
Add
Click Add to add any port into the MAC filtering table.
No.
This is the index number for the MAC filtering rules.
MAC Address
This field displays the MAC address that will be filtered.
VLAN
This is the VLAN group to which the MAC address belongs.
Filter
This field displays the action of the filter.
Name
This field displays the descriptive name for this rule. This is for
identification purpose only.
Select
Click on the checkbox for the MAC filtering rule you want to delete.
3.4.3 802.1X
3.4.3.1 802.1X Setting
Use this screen to activate IEEE 802.1x security and configure RADIUS server settings.
Click Security > 802.1x > 802.1x Setting to display the configuration screen as shown
