C HAPTER 1
A BOUT THE S WITCH
Overview
The LevelOne GSW-1676 and GSW-2476 are intelligent Layer 2
WebSmart Switches with 16 or 24 10/100/1000BASE-T ports, four of
which are combination ports
*
that are shared with four SFP transceiver
slots (see Figure 1-1, Ports 21-24 on the GSW-2476 and Ports 13-16 on the
GSW-1676).
Figure 1-1 Front Panels
