C ONNECTIVITY R ULES
4-7
100 Mbps Fast Ethernet Collision Domain
10 Mbps Ethernet Collision Domain
Table 4-3 Maximum 1000BASE-LX Fiber Optic Cable Length
Fiber Diameter Fiber
Bandwidth
Cable Length
Range
Connector
9/125 micron
single-mode fiber
N/A 2 m - 10km
(7 ft - 6.4 miles)
LC
Table 4-4 Maximum 1000BASE-ZX Fiber Optic Cable Length
Fiber Diameter Fiber
Bandwidth
Cable Length
Range
Connector
9/125 micron
single-mode fiber
N/A 2 m - 70 km
(7 ft - 43.5 miles)
LC
Table 4-5 Maximum Fast Ethernet Cable Length
Type Cable Type Maximum Cable
Length
Connector
100BASE-TX Category 5 or better
100-ohm UTP or STP
100 m (328 ft) RJ-45
Table 4-6 Maximum Ethernet Cable Length
Type Cable Type Maximum Length Connector
10BASE-T Categories 3, 4, 5 or
better 100-ohm UTP
100 m (328 ft) RJ-45
