LevelOne GSW-1676 - Table 1-1 Port Status Leds; Table 1-2 Power Status LED; Figure 1-3 Port Leds and Power LED

A BOUT THE S WITCH
1-4
Figure 1-3 Port LEDs and Power LED
Table 1-1 Port Status LEDs
LED Condition Status
Fast Ethernet Ports (Ports 1-16/24)
Link/Act
(Link/Activity)
On/Flashing
Green
Port has established a valid network connection.
Flashing indicates activity.
Off There is no valid link on the port.
1000 Mbps On Green Port is operating at 1000 Mbps.
Off Port is operating at 10 or 100 Mbps.
Table 1-2 Power Status LED
LED Condition Status
Power Green Internal power is operating normally.
Off Power off.
