C
ONFIGURING
THE
S
WITCH
6-12
Received Multicast Packets The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a multicast
address at this sub-layer.
Received Broadcast Packets The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a broadcast
address at this sub-layer.
Transmitted Octets The total number of octets transmitted out of the interface,
including framing characters.
Transmitted Unicast Packets The total number of packets that higher-level protocols
requested be transmitted to a subnetwork-unicast address,
including those that were discarded or not sent.
Transmitted Errors The number of outbound packets that could not be
transmitted because of errors.
Received Medium Priority
Packets
The total number of received packets that are set as
Medium Priority in the QoS settings.
Received Low Priority Packets The total number of received packets that are set as Low
Priority in the QoS settings.
Transmitted Medium Priority
Packets
The total number of transmitted packets that are set as
Medium Priority in the QoS settings.
Transmitted Low Priority
Packets
The total number of transmitted packets that are set as Low
Priority in the QoS settings.
RMON Statistics
Drop Events The total number of events in which packets were dropped
due to lack of resources.
Received Frames The total number of frames (bad, broadcast and multicast)
received.
Multicast Frames The total number of good frames received that were
directed to this multicast address.
Undersize Frames The total number of frames received that were less than 64
octets long (excluding framing bits, but including FCS
octets) and were otherwise well formed.
Fragments The total number of frames received that were less than 64
octets in length (excluding framing bits, but including FCS
octets) and had either an FCS or alignment error.
Port Statistics (Continued)
Parameter Description
