Repair information 4-25
5022-xxx
Rear cover removal
See “Rear cover” on page 7-3 for the part number.
1. Loosen the eight screws (A).
Note: Do not remove the screws.
2. Lift up on the rear cover, and slide to the right to remove from the back of the printer.
A
