Lexmark CS720 User Manual

Action Yes No
Step 5
Check the cable on the motor and on the JMTR1 connector on the
controller board for proper connection.
Is the cable properly connected at both ends?
Go to step 7. Go to step 6.
Step 6
Reconnect the cable.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Check the cable for damage, and replace if necessary.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Replace the controller board. See
“Controller board removal” on
page 357.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Transfer module thermistor service check
Action Yes No
Step 1
Check the cable on the JTHM1 connector on the controller board
for proper connection, and reseat if necessary.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
Replace the sensor (TPS). See
“Sensor (TPS) removal” on
page 325.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
5028
Diagnostic information
195
