6 Remove the four screws (E), and then remove the cover.
Duplex removals
Duplex outer guide removal
1 Remove the front cover. See “Front cover removal” on page 265.
2 Remove the pivot shaft. See “Pivot shaft removal” on page 291.
3 Remove the duplex inner guide. See “Duplex inner guide removal” on page 291.
5028
Repair information
289
