Lexmark CS720 - Output bin Exit Cover Removal

Output bin exit cover removal
1 Remove the top cover. See “Top cover removal” on page 268.
2 Disengage the tab (A), and then remove the cable from the tabs.
A
3 Remove the cover.
Output bin flag removal
1 Remove the top cover. See “Top cover removal” on page 268.
2 Remove the output bin exit cover. See “Output bin exit cover removal” on page 367.
5028
Repair information
367
