Connector Connects to Pin no. Signal
JTPSAA1 TPS and auto align sensors 1 VS10_TPS1_VDD
2TPS1_DIFF
3TPS1_SPEC
4GND
5TPS1_SPEC_G
6TPS1_LED_G
7 I2C_DATA_TPS
8I2C_CLK_TPS
9 VS10_TPS1_VDD
10 GND
11 AA1_ADC
12 AA1_PWM
13 VS10_TPS1_VDD
14 GND
15 AA2_ADC
16 AA2_PWM
JSHUT1 Media sensor 1 VS10_SHTR
2S_SHTR
3GND
JPKSNS1 Isolation unit sensors 1 VS10_S1
2S_S1_IN
3GND
4VS10_S1_ALT
5S_S1_ALT_IN
6GND
7VS10_BAN
8S_BAN_IN
9GND
10 VS10_S2
11 S_S2_IN
12 GND
5028
Component locations
396
