Assembly 2: Covers 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X0414 1 1 Toner door
“Toner door removal” on page 276
2 41X0558 1 2 Toner door mount
bracket
“Toner door mount bracket removal” on
page 278
3 41X0415 1 1 Toner door mount
“Toner door mount removal” on
page 279
441X0412 1 1Left cover
“Left cover removal” on page 271
NS 41X1009 1 1 External air filter
“External air filter removal” on page
280
5028
Parts catalog
416
