Lexmark CS720 User Manual

Assembly 10: Electrical
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X0267 1 1Controller board
“Controller board removal” on
page 357
241X0394 1 1TMC card
“TMC card removal” on
page 315
3 41X0785 1 1 Sensor (weather station)
“Sensor (weather station)
removal ” on page 311
4 41X0270 1 1 High voltage power supply
“HVPS removal” on page 319
5 41X0382 1 1 Toner cartridge contact
“Toner cartridge contacts
removal” on page 328
6 41X0486 1 1 Sensor (waste toner contact)
“Sensor (waste toner contact)
removal ” on page 314
741X0566 1 1Sensor (MPF paper present)
“Sensor (MPF paper present)
removal” on page 322
8 41X0450 1 1 Sensor (media type)
“Sensor (media type) removal”
on page 340
9 41X0385 1 1 Sensor (input)
“Sensor (input) removal” on
page 341
10 41X0578 1 3 TPS wipers
“TPS wiper removal” on
page 332
11 41X0383 1 1 Sensor (TPS)
“Sensor (TPS) removal” on
page 325
12 41X0441 1 1 Control panel USB cable --
13 41X0425 1 1 Low voltage power supply
“LVPS removal” on page 305
14 41X0398 1 1 Fuser fan
“Fuser fan removal” on
page 299
15 41X0397 1 1 Main fan
“Main fan removal” on page
301
NS 41X0719 1 1 Control panel cable kit --
NS 41X0575 1 1 TPS cable --
5028
Parts catalog
432
