5 Disconnect the sensor cable, and then remove the sensor retainer (C).
C
6 Remove the sensor.
HCOE drive belt removal
1 Remove the HCOE right cover. See “HCOE right cover removal” on page 549.
2 Remove the HCOE latch. See “HCOE latch removal” on page 554.
3 Remove the HCOE bin pinion. See “HCOE bin pinion removal” on page 558.
4064
Parts removal
561

Lexmark M52 Series Specifications

General

Print Technology	Laser
Print Resolution, Black	Up to 1200 x 1200 dpi
Connectivity, Standard	USB 2.0, Ethernet
Network Connectivity	Ethernet
Media Types Supported	Card Stock, Envelopes, Plain Paper, Transparencies
Operating Systems Supported	Windows, macOS, Linux
