Output expander transport drive
1 Transport roller 1
2 Transport roller 2
3 Exit roller
4 Diverter
5 Motor (transport)
The transport rollers and exit roller along the paper path move the paper depending on the destination bin
assigned for the print job.
The motor (transport) drives both the transport and exit rollers.
4064
Theory of operation
893
