Lexmark M52 Series - Lower Transport Drive

Lower transport drive
1
2
1 Motor (MPF)
2 Lower aligner roller
The motor (MPF) also drives the lower aligner roller.
The roller receives the paper fed from the standard tray or the optional trays.
4064
Theory of operation
