Lexmark M52 Series - Optional 250- and 550-Sheet Tray Operation; 250- and 550-Sheet Tray Paper Path Rollers

Optional 250- and 550-sheet tray operation
250‑ and 550‑sheet tray paper path rollers
1 Transport rollers
2 Pick roller
3 Pass‑through path
4 Feed path
Paper from the optional trays is fed into the printer through the pick rollers.
Multiple optional trays use the transport rollers to receive paper from the lower trays.
