EXTERNAL EQUIPMENT SETUP
12
EXTERNAL EQUIPMENT SETUP
HD RECEIVER SETUP
This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you
do receive digital signals from a digital set-top box or other digital external device, refer to the figure as
shown below.
This TV supports HDCP (High-bandwidth Digital Contents Protection) protocol for Digital Contents (480p,
576p, 720p, 1080i, 1080p).
HDMI/DVI IN
2
1
RGB IN
RGB (PC)
S-
(CO
DIGITAL
AUDIO OUT
COMPONENT INCOMPONENT IN
VIDEOVIDEO AUDIOAUDIO
Y L RP B P R
HDMI/DVI IN
2
1
COMPONENT IN
VIDEO AUDIO
DIGITAL
AUDIO OUT
RGB IN
RGB (PC)
AUDIO
(RGB/DVI)
COMPONENT IN
VIDEO AUDIO
RGB IN
RGB (PC)
DIGITAL
AUDIO OUT
HDMI/DVI IN
COMPONENT IN
VIDEO AUDIO
DIGITAL
AUDIO OUT
HDMI/DVI IN
RGB IN
AUDIO
(RGB/DVI)
2
(DVI)
(DVI)
(DVI)
(DVI)
When connecting with a Component cables
Connect the video outputs
(
Y, PB, PR
)
of the digital set
top box to the CCOOMMPPOONNEENNTT IINN VVIIDDEEOO 11 jacks on
the set. Match the jack colors
(Y = green, P
B = blue, and PR = red)
Connect the audio output of the digital set-top box to
the CCOOMMPPOONNEENNTT IINN AAUUDDIIOO 11 jacks on the set.
Turn on the digital set-top box.
(
Refer to the owner’s manual for the digital set-top box.
)
Select CCoommppoonneenntt 11 input source using the IINNPPUUTT
button on the remote control.
If connected to CCOOMMPPOONNEENNTT IINN 22 input, select
CCoommppoonneenntt 22 input source.
2
1
Signal
480i
480p
576i
576p
720p
1080 i
1080 p
Component 1/2
Yes
Yes
Yes
Yes
Yes
Yes
No
HDMI1/DVI, HDMI2
No
Yes
No
Yes
Yes
Yes
Yes
