MULTI V 5 Outdoor Unit Service Manual
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
PCBs
OUTDOOR UNIT PARTS
External PCB
CN22_AC_PATH_YL
CN_WRITE_RD
CN_LGMV_YL
CN09_CYCLE_BL
CN40_EEV1_H_RD
CN41_EEV2_L_WH
CN42_SC_EEV_BL
CN44_VI_EEV1_OR
CN45_VI_EEV2_BR
CN36_TEMP1_GR
CN37_TEMP2_YL
CN38_TEMP3_VI
CN39_TEMP4_BK
CN09_OIL_C1_YL
CN08_OIL_C2_BR
CN34_P_H_RD
CN33_P_L_BL
CN32_HUMID_BK
CN31_SNOW_WH
CN10_AC_IN_WH
CN25_BASEPAN_BK
CN23_INJ_SUC_GY
CN21_RCV_OUT_GR
CN19_HEX_H_WH
CN17_OILBAL2_OR
CN15_4WAY2_BR
CN12_SUMP_C2_YL
CN13_ACC_OIL_WH
CN28_HP_SW_GY
CN11_SUMP_C1_BL
CN14_4WAY1_BK
CN16_OILVAL1_VI
CN18_HEX_L_VI
CN22_RCV_IN_RD
Actual component appearances may differ depending on manufacturing
date, model, system type, etc.
