219
Parts
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
OUTDOOR UNIT PARTS
PCBs
Inverter PCB for 208-230V Outdoor Units (17kW)
CN_AC_OUT_BK
CN_AC_IN_BK
CN_FAN_15V_BK
CN_COMM_OUT_BL
CN_COMM_IN_RD
CN_LGMV_YL
CN_FLASH_RD
CN_DEB_WH
CN_INPUT_VOLT_T
CN_INPUT_VOLT_S
CN_INPUT_VOLT_R
CN_INPUT_VOLT_R
CN_INPUT_VOLT_R
CN_INPUT_VOLT_R
Actual component appearances may differ depending on manufacturing date, model, system type, etc.
